Spacing between low-voltage cable trays and power cable trays

Fiber and communications infrastructure knowledge brief Published 05 Apr 2025

Prepared for preliminary research by the ROGER FIBRE knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

The recommended spacing between power and low-voltage cable trays is generally at least 0. 5 meters (20 inches) horizontally, or 12 inches (300 mm) vertically, with reduced spacing possible if shielding is used.

Horizontal Spacing

To minimize electromagnetic interference (EMI) and maintain signal integrity, power and low-voltage (signal or communication) cable trays should be separated horizontally by at least 0. 5 meters (20 inches) under typical conditions. If the trays are shielded, this distance can be reduced to 0.

3 meters (12 inches) while still controlling EMI effectively. For long parallel runs of high-current power cables, some engineering practices recommend even greater separation to ensure optimal signal performance.

Vertical Spacing

When trays are stacked vertically, a minimum clearance of 150 mm (6 inches) is recommended between the upper and lower trays. This spacing allows for proper ventilation, heat dissipation, and future cable expansion or rearrangement. Industry standards often suggest placing power trays above low-voltage or instrumentation trays to further reduce interference.

NEC Guidelines

The National Electrical Code (NEC) specifies minimum separation distances for communication and power cables. For parallel runs, NEC Article 800. 133(A)(1)(c) requires at least 50 mm (2 inches) between communication circuits and non-communication raceways, with perpendicular crossings allowed to reduce exposure.

While this is a baseline, best practices in industrial installations typically exceed this minimum to ensure safety and signal quality.

Additional Considerations

Shielding: Using metal partitions or shielded trays can reduce required spacing and mitigate EMI. Support and Maintenance: Adequate spacing ensures easy access for inspection, maintenance, and cable installation. Environmental Factors: High-temperature or high-humidity environments may require additional spacing to prevent overheating and maintain cable integrity.

By following these guidelines, installations can achieve both electrical safety and signal reliability, while complying with NEC standards and industry best practices.
