XM type distribution box

The XM type distribution box is a versatile low-voltage electrical distribution unit designed for safe power distribution, overload and short-circuit protection, and circuit switching in residential, commercial, and industrial applications.

Overview

The X

M series distribution box is widely used in power plants, factories, mines, hotels, apartments, high-rise buildings, ports, railway stations, airports, and warehouses. It is suitable for AC single-phase 220V or three-phase 380V systems, with rated currents ranging from 80A to 630A, depending on the model. These boxes are designed for indoor and outdoor use and can be operated safely by non-professionals in civilian settings.

Key Features

Protection Functions: Provides overload, short-circuit, leakage, and over-voltage protection, ensuring safe operation of electrical circuits. Construction: Made from high-quality cold-rolled or galvanized steel plates, typically 2. 0mm thick, with epoxy resin electrostatic spraying for durability, corrosion resistance, and aesthetic appeal.

Design: Compact and robust, with clear labeling and easy access for maintenance. Supports single-phase, three-wire, or three-phase five-wire circuits. Standards Compliance: Conforms to IEC60439.

1-1992, GB7251. 1-2005, GB7251. 3-2017, ensuring safety and reliability.

Installation: Can be installed visibly or hidden, with flexible electrical schemes and modular combination options for scalability. ApplicationsXM distribution boxes are used for lighting distribution, power distribution, metering, and control of electrical equipment in various environments, including industrial, commercial, and residential settings. They are suitable for secondary power distribution and can manage lighting, motor loads, and other low-voltage circuits efficiently.

Environmental and Operational Requirements

Ambient Temperature: -5°C to +40°CHumidity: Up to 50% at +40°C; higher humidity acceptable at lower temperaturesAltitude: Up to 2000 meters above sea levelPollution Grade: Level 3 SummaryThe XM type distribution box is a reliable, safe, and flexible solution for low-voltage power distribution. Its robust construction, multiple protection features, and compliance with international standards make it suitable for a wide range of applications, from residential buildings to industrial facilities.
