What type of cable tray is a mesh cable tray

Fiber and communications infrastructure knowledge brief Published 19 May 2024

Prepared for preliminary research by the ROGER FIBRE knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Mesh-type cable trays, also known as wire basket trays, are open, lightweight, and flexible systems designed for efficient cable management in industrial, commercial, and high-tech installations.

Overview

Mesh cable trays are constructed from high-strength steel wires welded into a grid or basket-like structure, providing a durable yet lightweight support system for electrical, communication, and fiber optic cables. They are typically open in design, allowing excellent ventilation, preventing heat buildup, and reducing the accumulation of dust and debris. This open structure also enables easy cable entry and exit at any point, simplifying installation and maintenance.

Materials and Surface Finishes

Mesh trays are available in various materials and surface treatments to suit different environments: Steel (hot-dip galvanized): Suitable for industrial applications with high load requirements. Stainless steel: Ideal for food, chemical, or corrosive environments. Electro-galvanized steel: Suitable for interior areas without special corrosion requirements.

The trays can also come in different side heights to accommodate varying cable volumes and support heavier loads, with some heavy-duty designs capable of handling up to 110% more load than standard trays.

Advantages

Flexibility: Easily bent or branched to create turns, exits, or junctions without cutting or welding. Cost-effective: Cheaper than fully enclosed conduit systems and reduces installation time. Easy maintenance: Cables are visible and accessible for inspection, repair, or replacement.

High load capacity: Certain heavy-duty mesh trays support larger cable bundles and wider support spacing up to 4 meters. Safety: Open design reduces fire hazards by preventing heat accumulation and allows for regular inspection.

Applications

Mesh cable trays are widely used in: Industrial plants: For power, control, and communication cables. Data centers and IT infrastructure: For fiber optic and sensitive cabling requiring organized routing. Commercial buildings: For flexible and scalable cable management.

Food and chemical industries: Using stainless steel trays to resist corrosion.

Installation Considerations

Can be wall-mounted, ceiling-suspended, or underfloor depending on project requirements. Ensure proper bend radius for fiber optic and coaxial cables to prevent signal loss. Regular cleaning is recommended to prevent dust accumulation, especially in industrial environments.

Selection of tray type, size, and material should be based on cable quantity, weight, environmental conditions, and project specifications. Mesh-type cable trays provide a versatile, durable, and cost-efficient solution for modern cable management, combining high load capacity, easy access, and adaptability for complex installations.
