100kV Distribution Box Specifications

Fiber and communications infrastructure knowledge brief Published 01 Mar 2025

Prepared for preliminary research by the ROGER FIBRE knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

A 100kV distribution box is designed with robust construction, proper busbar sizing, isolators, fuses, cable entry, and safety features to ensure reliable low-tension power distribution.

Construction and Materials

The box is typically fabricated from 2 mm GI or CRCA steel sheets with reinforced channels for structural strength and outdoor durability. Doors are horizontally opening with a minimum 90° swing, equipped with Godrej-type three-way locking systems for security. Hinges are mounted internally to prevent tampering, and the box includes dust, vermin, and rain protection using perforated stainless steel sheets and rubber linings.

The roof is slightly slanted with overhangs to prevent water ingress.

Busbars and Electrical Components

Phase busbars: EC grade aluminum, sized 72x50x8 mm for 63/100 KVA boxes. Feeders and incomer droppers: 50x8 mm for 63/100 KVA boxes, with proper drilling and PVC insulation. Neutral busbar: Isolated from the body, with bimetallic lugs and earthing provisions on both sides.

MCC

Bs: Triple-pole for outgoing circuits, with heat-resistant barriers between units. Switch disconnectors: Four-pole, padlockable in OFF position, with IP-20 front protection covers and inbuilt phase barriers.

Isolators and Fuses

Isolators: Robust, easy to operate, with arc-chutes (minimum 12 strips) to extinguish arcs. Porcelain fuse units: As per IS: 2086/1993, used for incoming and outgoing protection.

Kit-

Kat fuse connections: Insulated with heat-shrinkable sleeves for safety.

Cable Entry and Termination

Cable glands: Heavy-duty, double compression type, with rubber films to seal cables and prevent dust ingress. Bottom plates: Provided with holes and rubber glands for incoming and outgoing cables, typically 125x125 mm.

Earthing and Safety

Earthing points: Solid, zinc-plated clamps on both sides of the box. Phase barriers and insulation: Ensure safe operation and prevent accidental contact or arc travel between phases. Temperature management: Ventilation provisions maintain component temperature within safe limits.

Standards and Compliance

Conforms to IS: 2062/2011, IS: 13947, IS: 2086/1993, and other relevant IS standards. IP-55 protection for outdoor installation, verified through type tests at CPRI or NABL-accredited labs. Optional FeaturesLT CT operated meters with communication for DT metering.

Automatic Power Factor Controllers on incoming circuits. Modular designs like APC PDPM100F6F-M allow scalable addition of circuits and cord-sets for 100kVA applications. This configuration ensures reliable, safe, and maintainable low-tension distribution for 100kV systems, suitable for mounting below transformers or on PSC/Girder poles, with provisions for both operational efficiency and personnel safety.
