Installation sequence of fiberglass cable trays

Fiberglass cable trays should be installed section by section with proper supports, alignment, and secure connections to ensure structural integrity and safe cable management. 1.

Preparation and Planning

Review construction drawings and conduct an on-site inspection to determine tray routes, installation height, support spacing, and layer structure. Pre-measure bends, ramps, and T-junctions in complex environments such as underground shafts or elevated supports. Verify that the load-bearing capacity of the tray matches the expected cable load to prevent deformation.

Inspect all materials (trays, supports, connectors, fasteners) for cracks, delamination, or broken edges. Protect trays during transport and handling from impacts, drops, or prolonged sun exposure. 2.

Tools and Equipment

Measuring tape, spirit level, and marking tools for accurate placement. Power drill with appropriate bits for mounting brackets or hangers. Circular saw with abrasive cut-off wheel or hack saw for field cutting, if necessary.

Carbide-tipped drill bits and saw blades for large quantities. Torque wrench for tightening nuts to recommended torque (3–4 ft.-lbs.),. 3.

Installing Supports

Install supports (trapezes, brackets, or hangers) according to design specifications, ensuring spacing does not exceed the distance between splice plates. When hanging from beams, use appropriate clamps and ensure full engagement of threaded rods. Maintain a maximum 2-inch gap between the tray and supporting rod.

4.

Assembling and Installing Trays

Install trays section by section, connecting each segment with splice plates, bolts, and washers. Ensure trays are level, joints are aligned, and there are no excessive gaps. Use standard GRP fittings (horizontal bends, vertical bends, tees, crosses) for turns, rises, or branches.

Avoid on-site cutting or makeshift splicing to maintain structural integrity. 5.

Cable Laying and Securing

Label, sort, and bundle cables before installation, using flame-retardant cable ties. Allow sufficient slack for thermal expansion and contraction. For wall or floor penetrations, use protective sleeves and fire-stopping materials.

Ensure cables are evenly distributed and secured to prevent shifting during operation. 6.

Finishing and Inspection

Install tray covers to protect against dust, falling objects, and mechanical damage. Conduct a full inspection to ensure all joints are secure, supports are stable, and fasteners are tight. Design and implement a grounding system if required.

7.

Safety and Compliance

Maintain safe distances from electrical equipment to avoid interference or hazards. Follow national and local electrical codes, such as NEC or CEC, and manufacturer installation standards. Only qualified personnel should perform installation, following proper safety procedures.

By following these steps, fiberglass cable trays can be installed safely, efficiently, and in compliance with engineering and electrical standards, ensuring long-term durability and reliable cable management.
